HYDRAULIC DEMOLITION SHEAR
Okada-832-x-848
HYDRAULIC DEMOLITION SHEAR
okada new

Okada Aiyon Corporation have been manufacturing since 1938, they are established as one of the leading worldwide demolition attachment manufacturers whose demolition shears are acclaimed for their unique curved blade design resulting in excellent performance - this shear cuts through steel with complete ease, see video below!

TS-S copy
  • OPERATING WEIGHT : 780kg
  • CUTTER BLADE LENGTH : 320/380 mm
  • JAW OPENING : 475 mm
  • SPEED VALUE : ‚úst
  • CUTTING FORCE : 745kN
  • EXCAVATOR : 6 - 9T
  • HYDRAULIC ROTATION : ‚úst
  • OPERATING WEIGHT : 1460kg
  • CUTTER BLADE LENGTH : 420/500 mm
  • JAW OPENING : 565 mm
  • SPEED VALUE : ‚úst
  • CUTTING FORCE : 1080kN
  • EXCAVATOR : 10 - 25T
  • HYDRAULIC ROTATION : ‚úst
  • OPERATING WEIGHT : 2510kg
  • CUTTER BLADE LENGTH : 550/600 mm
  • JAW OPENING : 690 mm
  • SPEED VALUE : ‚úst
  • CUTTING FORCE : 1910kN
  • EXCAVATOR : 20 -35T
  • HYDRAULIC ROTATION : ‚úď
  • OPERATING WEIGHT : 3630kg
  • CUTTER BLADE LENGTH : 660/720 Kg
  • JAW OPENING : 815 mm
  • SPEED VALUE : ‚úst
  • CUTTING FORCE : 2310kN
  • EXCAVATOR : 30 - 50T
  • HYDRAULIC ROTATION : ‚úď

     Features include:

  • Innovative¬†curved blade design for unbeatable cutting performance.
  • Tooth at the end of the jaw used to bend back RSJ beams during cutting.
  • All Okada demolition shears are designed, tested and manufactured in Osaka, Japan.
  • Oil flow speed valve, built into crusher cylinders, reduces cycle time -¬†very fast operation.
  • Cast body¬†makes for a lighter attachment with superior durability.
  • Short body shape -¬†easy to operate¬†the hydraulic shear.

     Features include:

  • Innovative¬†curved blade design for unbeatable cutting performance.
  • Tooth at the end of the jaw used to bend back RSJ beams during cutting.
  • All Okada demolition shears are designed, tested and manufactured in Osaka, Japan.
  • Oil flow speed valve, built into crusher cylinders, reduces cycle time -¬†very fast operation.
  • Cast body¬†makes for a lighter attachment with superior durability.
  • Short body shape -¬†easy to operate¬†the hydraulic shear.

     Features include:

  • Innovative¬†curved blade design for unbeatable cutting performance.
  • Tooth at the end of the jaw used to bend back RSJ beams during cutting.
  • All Okada demolition shears are designed, tested and manufactured in Osaka, Japan.
  • Oil flow speed valve, built into crusher cylinders, reduces cycle time -¬†very fast operation.
  • Cast body¬†makes for a lighter attachment with superior durability.
  • Short body shape -¬†easy to operate¬†the hydraulic shear.
TS-S Demo Mag - Crop
TSS550 - Editorial
Model TS-S 320 TS-S 430 TS-S 550 TS-S 660
OPERATING WEIGHT780Kg1460Kg2510Kg3630Kg
CUTTER BLADE LENGTH320/380 mm420/500 mm550/600 mm660/720 mm
JAW OPENING475mm565mm690mm815mm
SPEED VALUE‚úď‚úď‚úď‚úď
CUTTING FORCE745KN1080KN1910KN2310KN
EXCAVATOR6 - 9 T10 - 25 T20 -35 T30 -50 T
HYDRAULIC ROTATION‚úď‚úď‚úď‚úď
